Material thickness | 50-300 mic |
Roll effective width | 1300mm, 1600mm |
Unwind diameter | 1000mm, 1200mm |
Min Slitting width | 5mm |
Rewind diameter | 650mm, 800mm |
Machine speed | 300M/MIN. |
Feature
1. Unwind unit: shaftless (optional) unwind stand with 3” & 6” cone chucks
2. Automatic web guide control: EPC/LPC
3. Automatic tension control
4. Rewind duplex differential shaft with slip ring fully arranged
5. Japan Mitsubishi PLC programmable control
6. Edge trimming by fan blower (side type) / spool trim winder machine (optional)
7. Infrared fray auxiliary core positioning system to save time
8. Auto push-off device with finished reel unloader system
9. Slitting blade: razor blade (in air or groove type), shear blade (optional)
